Product Detail
The mixing effect is uniform, and its scope of application is wide. The forced stirrer can also be equipped to meet the requirements of raw materials that contain fine powder and certain moisture, as requested.
The machine is suitable for mixing 2 or more dry and powder or granular raw materials from the industry and, chemical industry. foodstuff industry and so on.
The structure of this machine is unique, its mixing efficiency is high, and no dead corners. It is made of stainless steel, inner and outer walls are processed through polishing. Its appearance is beautiful.
The mixing effect is uniform, its scope of application is wide, and the forced stirrer can also be equipped to meet the
requirement of raw materials that contain fine powder, and certain moisture as requested.
The mixing effect is uniform, its scope of application is wide, and the forced stirrer can also be equipped to meet the
requirement of raw materials that contain fine powder, and certain moisture as requested.
Specifications
|
Model and specification
|
0.18
|
0.3
|
0.5
|
1.0
|
1.5
|
2.0
|
2.5
|
|
Productive capacity (kg/time)
|
72
|
120
|
200
|
400
|
1600
|
800
|
1000
|
|
Model of vacuum pump
|
W2
|
W2
|
W2
|
W3
|
W3
|
W3
|
W3
|
|
Time of raw material fed in (min)
|
3-5
|
3-5
|
4-6
|
6-9
|
6-10
|
8-13
|
8-15
|
|
Mixing time (min)
|
4-8
|
6-10
|
6-10
|
6-10
|
6-10
|
6-10
|
6-10
|
|
Total volume (m3)
|
0.18
|
0.3
|
0.5
|
1.0
|
1.5
|
2.0
|
2.5
|
|
Stirring speed (r/min)
|
12
|
12
|
12
|
12
|
12
|
12
|
12
|
|
Power of motor (kw)
|
1.1
|
1.1
|
2.2
|
4
|
4
|
5
|
7.5
|
|
Rotating height (mm)
|
1580
|
1760
|
2400
|
2840
|
3010
|
3240
|
3680
|
|
Weight (kg)
|
280
|
320
|
550
|
950
|
1020
|
1600
|
2040
|
Applications
Applicable Industries:
Building Material Shops, Machinery Repair Shops, Restaurant, Food Shop, Energy & Mining, Food & Beverage Shops
