CH Series U Style Automatic Trough Type Ginger Powder And Honey Mixer Mixing Machine

You are here:
 > CH Series U Style Automatic Trough Type Ginger Powder And Honey Mixer Mixing Machine

CH Series U Style Automatic Trough Type Ginger Powder And Honey Mixer Mixing Machine

Mixer Type: Agitator
Material Processed: Chemicals, Food
Weight (KG): 40 KG
Condition: New
Place of Origin: Jiangsu, China
Power (kW): 0.25 kW
Warranty: 1 Year
Key Selling Points: Easy to Operate
Warranty of core components: 1 Year
Core Components: Bearing
Range of Spindle Speed(r.p.m): 20 – 25 r.p.m
Max. Loading Capacity: 10-500L
Material: SUS304
Product Type: CH10–CH500 Type Mixer

Table of Contents

Product Detail

1-Description
The contact part with material of CH series tough type blender machine is made of stainless steel. The gap between the blade and inner wall is slim and there is no hidden corner during mixing. The stirring axis is fixed with sealing on both ends which can prevent material leaking outside. The hopper is controlled by buttons, and its discharging is convenient.

2-Application
CH series trough type blender machine is used for blending powder or wet material to make the different ratio of materials mixed evenly, it is widely applied to mix material in industry, foodstuff industry, chemical industry, electronic industry and so on. It is especially suitable for the condition that the materials have big proportion difference and the needed uniformity is high.


3-Features
1-CH series trough type blender machine has the features of compact structure, simple operation, nice appearance, small occupied place, easy cleaning and great mixing etc.
2-The blender set makes S shape stirring blade rotate though mechanical drive to force the material stir to-and-fro thus makes the blending even. The operation is controlled by electric controller, and the mixing time can be set according needs, when it reaches the set value, it will stop automatically.

Specifications

Model
Volume(m3)
Feed amount
(kg/batch)
Overall size (mm)
Mixing time (min)
Stir speed (r/min)
Motor powder (kw)
Powder of discharging motor (kw)
50
0.05
38
1300*1000*540
6-15
28
1.5
0.55
100
0.10
83
1400*1100*600
6-15
26
2.2
0.55
150
0.15
124
1360*1120*600
6-15
24
3
0.55
200
0.2
140
1460*1200*600
6-15
24
4
0.55
300
0.3
210
1820*1240*680
6-15
24
5.5
1.5
400
0.4
310
2000*1240*780
6-15
20
5.5-6
1.5
500
0.5
350
500*1240*780
6-15
18
7.5-6
2.2
750
0.75
560
2200*1240*780
6-15
16
7.5-6
2.2
1000
1.0
780
2300*1260*800
6-15
16
11-6
3
1500
1.5
1150
2500*1300*860
6-15
12
11-6
3
2000
2.0
1500
2600*1400*940
6-15
12
15-6
4
2500
2.5
2100
3000*1560*1160
8-20
12
18.5-6
5.5
3000
3.0
2250
3800*1780*1500
8-20
10
22-6
7.5

Applications

Applicable Industries: Food & Beverage Factory, Food Shop, Food & Beverage Shops
